40,000 Lumen 2K Projector Rental
The world’s brightest projector is now available for rental hire at your next event! With 2K resolution and at 40,000 lumens having a plethora of advanced features which include HD-Digital Cinema and being 3D ready, it has it all and guarantees an unequalled event experience! Its remarkable 2K resolution and high contrast ratio provides deep rich color saturation and brilliantly intense imagery for use on larger screens and surfaces. We can blend them, we can stack them… we can paint your whole building with moving imagery!!
The HDQ-2K40 is an amazing projection rental system with the convenience of Barco’s ImagePro technology built-in through the renowned Athena image scaler. Its modular design makes the HDQ simple to install and service; its solid, adjustable, and stackable frame makes it easy to rig. Extensive wireless features enable control of the projector’s many features and functions, including light-on-demand technology that allows full tuning of the HDQ’s light output to meet design needs. Typical applications include large venue rental and staging events, broadcast, Houses of worship, Digital Cinema and façade projection.
The HDQ-2K40 is compatible with the following Barco XLD lenses:
1.0, 1.45-1.8, 2.2-3.0, 1.8-2.4, 2.8-5.5, 5.5-8.5.
Note: Lenses rented separately.
Projector type: 2K 3-chip DLP digital projector
Technology: 1.2′ DMD™ x3
Resolution: 2048 x 1080
Brightness: 40,000 center lumens, 37,000 ANSI lumens
Contrast ratio: 2,000:1 (standard)
Brightness uniformity: 0.9
Aspect Ratio: 2048:1080 (16:9 approx)
ScenergiX: Horizontal and vertical edge blendingLens
Type: XLD
Lenses
Fixed
1:1
Zoom
1.45-1.8:1
1.8-2.4
2.2-3.0
2.8-5.5
5.5-8.5
Optical lens shift
Vertical: /-110%
Horizontal: /-30% (on zoom lenses memorized)
Color correction: P7Lamps
Type: 7 kW xenon
Lamp lifetime: 500 Hrs
Transport with lamp: No
Lamp house, quick replace: Yes
Customer bulb replace: Yes
Lamp warranty (field replace/ factory replace): 90 days, 500 hours / pro rata 500 hoursOther Features
Sealed DLP™ core: Standard
Optical dowser: Standard
Picture-in-picture: Two sources simultaneously
Preview mode: yes, with LCD display
WARP: Preset values custom
integrated web server: yes
CLO (constant light output): Standard
Inputs
Standard
DVI-I (HDCP including analog RGB YUV)
SDI/HDSDI/Dual HDSDI/3G/BarcoLink
Optional
5-BNC RGBHV (RGBS/RGsB, YUV CS/SOY, Composite video, S-Video)
DVI-I (HDCP including analog RGB YUV) SDI/HDSDI/Dual HDSDI/3G
Input Resolutions: From NTSC up to QXGA (2048×1536)
Pixel Clock: 200 MHz maximum
Control
Software tools: Projector Toolset
Control: XLR wired IR, RS232, Wifi, GSM (opt)
DMX 512: standard
Network connection: 10/100 base-T, RJ-45 connection, Wifi (optional)
Power
Requirements: 200-240V / 380-400V at 50-60Hz
Max. Consumption: 8,000W
Environmental
Operational ambient temperature: 32°to 104°F (0 to 35°C )
Operational humidity: 0-80% non condensing
Dissipation BTU: Max. 27,331 BTU/h
Noise level (typical at 25°C/77°F): 65dB(A)
Physical
Dimensions: 40.35″W x 51.96″L x 35.43″H (1025 x 1320 x 900mm)
Weight: 462.97 lbs (210kg)
Orientation: table – side (portrait)
Standard accessories
Power cord; wireless/XLR wired rugged remote control; adjustable frame/clamps
Certifications
UL60950-1 and EN60950-1
FCC part 15 Class A rules & regulations
CE EN55022 Class A, RoHS
